EN 16Mo3 Steel Plate Cutting Merchanical Propertites

EN 16Mo3 Steel Plate Cutting Merchanical Propertites

16Mo3 Steel is mainly used for boilers and pressure vessels with elevated temperatures according to EN 10028–2 (2003). It is equivalent to 15D3 (AFNOR 36206 ) and UNI5869 16Mo316Mo3 with Molybdenum alloy steel plates which is mainly used for constructing pressure vessels and boilers.

16M03 EN 10028-2 Number:1.5415	Comparision of steel grades
	DIN 17155	15 Mo03
	NFA 36-205	15 D3
	UNI 5869	15 M0 3
	BS 1501	1503 - 243 B
	UNE 36087	16 Mo 3
	ASTM	A 204 Gr. B
	JIS G3115	-

EN 16Mo3 steel Chemical Composition

Grade	C. max	Mn.	S.	N	Cu	Si.	P.	Cr.	Ni.	Mo.
16Mo3	0.12- 0.2	0.40- 0.90	0.01	0.012	0.30	0.35	0.025	0.30	0.30	0.25- 0.35

EN 16Mo3 steel Merchanical Propertites

Grade	Tensile Strength (Mpa)	Yield Strength (Mpa)	Elongation in 100-150 mm(%)	Elongation in 16 mm(%)	Max Thickness (mm)
16Mo3	440-590	220-275	19	24	250

EN 16Mo3 steel plate Standard

1. Thickness:3~200mm

2. Width:1500-3000mm

3. Length:1000~12000mm

EN 16Mo3 steel plate Surface treatment:

Normalizing /Tempering/Quenched/Anneal

As a EN 16Mo3 steel plate manufacturer, we usually keep hundreds tons EN 16Mo3 steel plate in stock each month. Based on these stock source, our advantage has spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, welding. We can also provide the EN 16Mo3 steel plate in machining parts and steel structure.
