You are here : section steel--Katalor steel > News > 正文A572 Grade 50 Channel Steel Strength, Weld ability, and Machinability

A572 Grade 50 Channel Steel Strength, Weld ability, and Machinability

A572 steel is available in five different grades: 42, 50, 55, 60, and 65. Each grade number indicates the yield strength of this high strength, low alloy steel. Grade 50 Channel Steel is mainly used in bridges, buildings, construction equipment, freight cars, machinery, truck parts, and other applications.

TYPICAL CHEMICAL PROPERTIES

Carbon Max, %	0.23
Manganese Max, %	1.35
Phosphorus Max, %	0.04
Sulfur Max, %	0.05

MECHANICAL PROPERTIES

Tensile Strength (PSI)	Yield Strength (PSI)	Elongation in 2"	Brinell Hardness
65,000	50,000	19	135

A572 Grade 50 Product Specification:

Item: ASTM A572-50 steel channel.,
Dimensions: UPN & UPE.
Web width: 80 - 200 mm.,
Web thickness: 6 - 8.5 mm (UPN) & 4.5 - 5.2 mm (UPE).
Flange width: 45 - 75 mm (UPN) & 40 - 76 mm (UPE).,
Flange thickness: 8 - 11.5 mm (UPN) & 7.4 - 9.0 mm (UPE).,
We can supply any size based on customer's requirements

Grade 50 Channel Steel Additional Condition

UT(Ultrasonic examination),AR(As Hot Rolled only),TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test(such as SGS Test),Coated or Shot Blasting and Painting.

Other Terms of A572 Grade 50:

◆ Packaging Details: Standard export seaworthy packing or as required.
◆ Delivery Time:20-30 days, 7days for stock goods.
◆ Loading Port: Shanghai
◆ Offer Ability:6000MT/Per Month.
◆ MOQ:1 Pcs.

Shanghai Katalor Enterprises Co., Ltd is specialized in supplying A572 Grade 50 Channel Steel. Besides that, Shanghai Katalor Enterprises Co., Ltd is also a manufacture, so we could promise the delivery time and the competitive price compared with other company. We sincerely hope new and regular customers come to visit our mill and inquiry A572 Grade 50 from Katalor.
